Product Details:
Minimum Order Quantity | 1 Piece |
Strapping Speed | 1.5 sec |
Type | Semi Automatic |
Material | Iron |
Usage/Application | Box Strapping |
Model | MY27 |
Capacity | 55 KG |
Brand | MONARCH |
Benefits: |
* Time saving |
* Main hour saving |
* Material saving |
* Better packing impact |
Additional Information:
Product Details:
Minimum Order Quantity | 1 Piece |
Phase | 1 Ph |
Voltage | 220 |
Model | MY27, My 27 |
Capacity | 1.5 sec./strap1.5 sec./strap AND 50 KG |
Brand | Monarch |
Power | 500 V |
Heigher Table | Lower Table | |
Strap Cyacle Speed | 1.5 sec./strap1.5 sec./strap | |
strap Width | 6 to 15 min. | 6 to 15 min. |
Sealing Method | Heat Sealed | Heat Sealed |
Min.Package Size | 60 mm(w) | 60 mm(w) |
Drive Motor | 250 V x 1( 1/4 H.P.) | 250 V x 1( 1/4 H.P.) |
Power Supply | 220 V 50 /60 Hz, 1 phase | |
Tension Strenght | 55 kg/max. | 55 kg/max. |
Machine Weight | Above 100 kg. | Above 90 kg. |
Dimention | 900 x 580 x 750 | 1450 x 580 x 505 |
Additional Information:
Product Details:
Minimum Order Quantity | 1 Piece |
Strapping Tension | Adjustable |
Phase | 1 Ph |
Voltage | 220 v |
Power | 500 w |
Brand | MONARCH |
Model | my27 |
Capacity | 55 kg |
Features * Instant heating in just 20 second . |
* Magnetic drive for faster & speed / packing . |
* Lift type top cover alows convenient maintenance. |
* Safety switch is activated as soon as top cover is opened. |
* Economic design of control switch , independent PCB control feeding and heating . The unit is easy to maintain |
* External adjustable tension knob on control panel provides easy and simple operation. |
* one touch machine operation energy saving mode activates in just 15 sec of non-use and allows for instant operation. |
* Stainless steel frame is available for strapping moisturised products. |
Additional Information:
Product Details:
Minimum Order Quantity | 1 Piece |
Weight | 100 kg |
Automation Grade | Semi-Automatic |
Machine Type | Table Type |
Packaging Material | Plastic |
Usage/Application | Carton Strapping |
Automatic Grade | Semi-Automatic |
Brand | Monarch |
Voltage (V/Hz) | 220 V |
Material | Metal |
Product Details:
Minimum Order Quantity | 1 Piece |
Brand | Monarch |
Strapping Tension | 50 kg |
Phase | 1 Ph |
Material | Mild Steel |
Driven Type | Electric |
Voltage | 110v,220-240v |
Power | 50-60hz |
Silent Features : |
* Instant heating in just 20 second . |
* Magnetic drive for faster & speed / packing . |
* Lift type top cover alows convenient maintenance. |
* Safety switch is activated as soon as top cover is opened. |
* Economic design of control switch , independent PCB control feeding and heating . The unit is easy to maintain |
* External adjustable tension knob on control panel provides easy and simple operation. |
* one touch machine operation energy saving mode activates in just 15 sec of non-use and allows for instant operation. |
* Stainless steel frame is available for strapping moisturised products. |
Additional Information:
Product Details:
Minimum Order Quantity | 1 Piece |
Capacity | Cycle time just 2.5 Sec., 22 strap per minutes |
Brand | MONARCH |
Phase | Single Phase |
weight | 250 kg. |
Size | 1420 X 700 X 1530 mm |
Tension Strength | 90 Kg. / Max. |
Silent Features : |
* High speed strapping |
* Cycle time just 2.5 Sec., 22 strap per minutes |
* Easy maintenance |
* No greasing required |
* Easy mechanical tension adjuster |
* Easy loading/unloading of strapping roll |
* Various model availavle |
* Fully automatic with belt drive |
* Fully automatic with roller drive |
* Variants in one, two, three strap option |
Product Details:
Minimum Order Quantity | 1 Piece |
Voltage | 220 v |
Brand | Monarch |
Capacity | 1.5 Sec./ strap |
Material | Mild Steel |
Phase | 1 Ph |
Driven Type | Motor |
Model | MY27 |
Strap Cycle Speed | 1.5 Sec./ strap |
Strap Width | 6 to 15 mm |
Strap Core Size | 200 mm |
Min. Package Size | 60 mm (W) |
Driving Motor | 0.25 H.R. |
Power Supply | 220 V 50 / 60 Hz, 1 Phase |
Tension Strength | 60 Kg./ Max. |
Machine Weight | 100 Kg. |
Dimensions | 900mm x 570mm x 750mm. |
Additional Information:
Product Details:
Minimum Order Quantity | 1 Piece |
Packaging Type | Box Packing Type |
Usage/Application | Box Strapping |
Model Name/Number | Tp-201 |
Brand | Monarch |
Driving Motor | 250 V x 1(1/4 H. P) |
Power | 220 V 50 / 60 Hz, 1 Phase |
Additional Information:
Product Details:
Minimum Order Quantity | 1 Piece |
Strapping Speed | 15 to 30 / Min. |
Model | TAIWAN |
Machine Grade | Semi-Automatic |
Capacity | 55 KG |
Phase | Single Phase |
Strapping Tension | Adjustable |
Brand | Monarch |
Strapping Machine Our company is well known in the market for the manufacture and supply of a wide range of Strapping Machine which have been made using a high quality of raw materials which have been procured from well known vendors. These products are used for sealing, erecting, filling and flap gluing the cartons of different sizes and they are used for packing various products in manufacturing industries and they are exported to the customers all over the globe.
Features
Other Details
Technical Specification
Strap Cycle Speed | 1.5 Sec./strap | 1.5 Sec./strap |
Strap width | 6 to 15 mm | 6 to 15 mm |
Sealing Method | Heat Sealed | Heat Sealed |
Min. package size | 60 mm(W) | 60 mm(W) |
Driving motor | 250 V x 1(1/4 H.P.) | 250 V x 1(1/4 H.P.) |
Power supply | 220 V 50 / 60 Hz, 1 phase | 220 V 50 / 60 Hz, 1 phase |
Tension strength | 55 kg./Max. | 55 kg./Max. |
Machine weight | above 100 kg. | above 90 kg. |
Dimension | 900 x 580 x 750 | 1450 x 580 x 505 |
Product Details:
Minimum Order Quantity | 1 Piece |
Brand | MONARCH |
Model Number/Name | MT27 |
Capacity | 55 KG |
Strapping Speed | 1.5 sec./ cycle |
Automation Grade | Semi-Automatic |
Strap Width | 6 -15mm |
Weight | 95kgs |
Model Number | Semi-Automatic Strapping Machine - JN 740 |
Dimensions | 895W x 570D x 735H /mm |
Sealing Method | Heat Sealing |
Tension Strength | 15 - 60 kgs |
Power Supply | 110/220V 50/60Hz single phase |
Table Top Strapping Machine
Specification:
